Table 4-1 Preventive Maintenance Checks and Services
Item Item to Not Fully Mission
No. Interval Check/Service Procedure Capable If:
11 B/A Activation Mode -Select A/L (AIM LO) using Activation Mode
Selector Switch the Activation Mode Selector Switch
and Integrated Selector Switch. inoperative with the
Momentary -Use the Integrated IR POINT or IR ILLUM
Activation Switch Momentary Activation Beam Spot not visible.
Switch and observe the
beam spot on wall through
(NVD necessary).
-Select A/H (AIM HI) and
repeat the activation.
-Repeat for each laser
activation position.
12 B Boresight -Confirm that the IR POINT
Alignment can be zeroed on the weapon
on which it will be mounted.
-Check to make sure that the
IR POINT projects on the
same side of the target as the
laser is mounted and falls within
10.2cm of the bore at 25 meters.
See Paragraph 3.5.
13 B/D/A LED Status -Observe green LED is lit
Indicator when lasing.
14 B/A Remote Cable -Insert the remote cable switch
Switch and activate the laser.
59
