Table 4-1 Preventive Maintenance Checks and Services
Malfunction Test / Inspection Corrective Action Ref. Para.
5. POINT beam a. Verify Quick Release Mount is -Properly position and 3.3
cannot be zeroed properly positioned/secured secure.
to weapon. to weapon.
b. If laser is loose on rail:
-Move to different position on rail.
-Move to different rail on weapon.
-Replace rail on weapon.
c. Inspect mount base for -Clean as required. 4.3.a
corrosion or dirt. -Notify Unit Maintenance.
6. Laser beam d. Verify DBAL-I
2
is properly -Notify Unit Maintenance.
cannot be zeroed secured to Quick Release Mount.
to weapon.
e. Verify Quick Release Mount is -Notify Unit Maintenance.
not damaged.
f. Check for beam movement. -Notify Unit Maintenance.
7. ILLUM knob a. Verify knob is free of mud -Clean as required. 4.3.a
turns, but beam and dirt. -Notify Unit Maintenance.
does not
change.
8. OIR pattern a. Verify IR ILLUM has been -Focus the IR ILLUM to a 3.2.h
is blurry or focused to a point. point.
unrecognizable. -Install different OIR.
-Notify Unit Maintenance.
63
