Steiner MD460 Owner/Operator's Manual & Illustrated Parts List

09-254B 6 - 7 rev 3/03
PARTS section 6
Parts List for Model MD472 - Figure 1B
Ref. Part No. Description Quantity
1 47-050 Knob, Ribbed W/ 1/4 Threads (Serial No. 1001 - 1837) 4
99-G03 Shakeproof Washer, 5/16" (Serial No. 1001 - 1837) 4
2 60-540 Shield, Top (Serial No. 1001 - 1016) 1
60-545 Shield, Top (Serial No. 1017 - 1837) 1
60-649.17 Top Shield W/Indicator Hole (Serial No. 1838 - ) 1
3 41-051 Spring, Ext 1.0 X 6.750 1
4 56-055-22 Chain, Idler (Serial No. 1001 - 2301) 1
5 64-534 Hook, Spring (Serial No. 1001 - 2301) 1
6 99-E20 Flange Nut, 1/4 2
7 29-010 Grease Fitting,1/4 Short 3
8 85-K0408 Key, 1/4 X 1 3
9 83-H16SPL Bushing,HX1"Split Type 3
10 83-BK80H Pulley, BK80H 3
11 90-0612 Bolt, 3/8 X 1-1/2 1
12 83-034 Idler, “V” 3/8" ID X 5" OD 2
13 95-06 Flat Washer, 3/8 SAE 2
14 62-733 Deck, Top (Serial No. 1001 - 1837) 1
62-840 Deck, Top (Serial No. 1838 - 2301) 1
62-873.17 Upper Deck Weldment MD472 (Serial No. 2302 - ) 1
15 99-E13 Flange Nut, 3/8 2
16 94-06 Flat Washer, 3/8 USS 3
18 85-B29 Bushing, .406 X.740 X.258 Thick 1
19 90-0614 Bolt, 3/8 X 1-3/4 1
20 40-292 Idler Arm (Serial No. 1001 - 2301) 1
40-330 Idler Arm MD472 (Serial No. 2302 - ) 1
21 99-E13 Flange Nut, 3/8 23
22 99-K22 Bolt, Flange 3/8 X 1-1/4 12
23 99-K11 Bolt, Flange 3/8 X 3/4 10
24 62-730 Deck, Mower (Serial No. 1001 - 1837) 1
62-841.17 Deck, Mower (Serial No. 1838 - ) 1
25 60-541.17 Chute, Side Discharge 1
26 87-143 Spindle, Mower 1/2-20 RH Threads 3
27 79-068 Blade, 24-3/4 .700 Air Lift 3
79-069 Blade, 24-3/4" 1-3/8 Air Lift (Optional) 3
28 99-B14 Washer, 1/4 X 1/2 IDX3OD 3
29 91-0810 Bolt, 1/2 X 1-1/4 NF 3
30 90-0608 Bolt, 3/8 X 1 1
31 64-799 Washer, 13/32 x 1-9/32 1
32 99-K39 Bolt, 1/4 X 1-1/2 Button Head (Serial No. 1017 - ) 2
33 95-04 Flat Washer, 1/4 SAE (Serial No. 1017 - ) 4 A/R
34 64-688 Spacer, Rotation Indicator (Serial No. 1017 - ) 2
35 00-137 Decal, Spiral Indicator (Serial No. 1017 - ) 1
60-568 Support, Rotate Indicator (Serial No. 1017 - ) 1
36 56-059-17 Trim-loc, Rubber 17" (Serial No. 1017 - ) 1
37 06-010 Cap Plug,1" (Serial No. 1017 - ) 1
* 00-139 Decal, Warning-Discharge Chute (Serial No. 1017 - ) 2
* 00-140 Decal, ANSI Certification (Serial No. 1017 - ) 1
* 00-138 Decal, Danger-Rotating Blade (Serial No. 1017 - ) 1
* 00-004 Decal, Steiner 1
* 00-092 Decal, Keep Hands & Feet 3
* 00-093 Decal, Warning-Read Owner's 1
* 00-129 Decal, Belt Installation 1
38 64-866 Shim, Spindle 22 Ga.(1 Pair) (Optional) 1 A/R
64-867 Shim, Spindle 16 Ga.(1 Pair) (Optional) 1 A/R
64-868 Shim, Spindle 12 Ga.(1 Pair) (Optional) 1 A/R
39 47-090 Latch, Rubber 3" Long (Serial No. 1838 - ) 4
40 04-008 Pop Rivet, 1/8 X 1/4 SS. (Serial No. 1838 - ) 8
41 04-007 Pop Rivet, 1/8 X 1/8 SS. (Serial No. 1838 - ) 8
42 64-900 Bracket, Top Shield Latch (Serial No. 1838 - ) 2
43 99-K31 Bolt, Flange 1/4 X 1/2 (Serial No. 1838 - ) 4
44 99-E20 Flange Nut, 1/4 (Serial No. 1838 - ) 4
* Not Illustrated
