Steiner MD460 Owner/Operator's Manual & Illustrated Parts List

8/01 1 - 1. 09-254B
INTRODUCTION section 1
Description
A full-floating rotary mower deck is designed to fit all Steiner power units with the quick hitch front lift.
Three sizes match the power unit to the application. These decks are easy to attach and detach allowing
interchange with the many other front mounted attachments. The side discharge rotary mower provides
even distribution of clippings while the full-floating deck follows the contours of the terrain for an even cut
with cutting height controlled by the front caster wheels and full width rear roller. The deck can be safely
serviced and cleaned while still attached to the tractor. Convenient handles enable the deck to be lifted
vertically over 90 degrees so the blades are fully exposed. Exceptional visibility and maneuvering is
possible with this front mounted design mower.
Specifications
MD448 MD460 MD472
Overall Width with Discharge Chute ____60-1/2" __________73"_____________85"
Overall Height ________________19" ____________19"_____________19"
Overall Length ________________49-1/2" __________48-3/4" __________55"
Cutting Width ________________47" ____________59-3/8" __________72"
Cutting Height ________________1"to4-1/2" ________1"to4-1/2" ________1"to4"
Blades ____________________3-16-1/4"blades ____3-20-1/2"blades _____3-24-3/4" blades
Weight ____________________330lbs. _________360lbs. __________470lbs.
NOTE:
The flip-up deck feature was
added beginning with the
following Serial Numbers;
MD448 - (S/N 1494)
MD460 - (S/N 4728)
MD472 - (S/N 1970)
