Steiner MD460 Owner/Operator's Manual & Illustrated Parts List

09-254B 6 - 11 rev 3/03
PARTS section 6
Parts List for Model MD460 - Figure 2A (Continued)
Ref. Part No. Description Quantity
5 62-695 Frame, Tube (Serial No. 1001 - 1194) 1
62-726.17 Frame, Tube (Serial No. 1195 - ) 1
6 90-0612 Bolt, 3/8 X 1-1/2 2
7 53-060 Hub Cap, For Mower 2
8 99-AC12NF Locknut, Center 3/4 2
9 95-12 Flat Washer, 3/4 SAE 4
10 55-Z9504AB Ball Bearing, 3/4 ID 4
11 99-B20 Washer, Mach 3/4 ID 14 GA. 8
12 50-049 Caster, Mower 2
13 90-0640 Bolt, 3/8 X 5 2
14 53-104 Wheel, 10.25 X 3.25 Caster (Serial No. 1001 - 6813) 2
55-G527 Bearing, Ball F/53-104 Wheel 2
55-107 Bearing, 5/8 ID x 1-3/8 OD (Optional, Heavy Duty) 2
53-186 Wheel, 10.25 X 3.25 Caster (Serial No. 6814 - ) 2
55-112 Bearing, Roller 5/8 ID x 1-3/8 1
53-187 Retainer, Flanged for 53-186 2
15 95-10 Flat Washer, 5/8 SAE 12
16 50-062 Axle Tube, Caster Wheel 2
17 94-06 Flat Washer, 3/8 USS 14 A/R
18 42-428.17 Link, Right (Serial No. 1001 - 1194) 1
42-444 Link, Right (Serial No. 1195 - ) 1
19 90-0610 Bolt, 3/8 X 1-1/4 3
20 99-A08 Locknut, Stover 1/2 3
21 42-427 Link, Front Left (Serial No. 1001 - 1194) 1
42-445 Link, Front Left (Serial No. 1195 - ) 1
22 42-430 Link, Height Adjust (Serial No. 1001 - 1194) 1
42-447.17 Link, Height Adjust (Serial No. 1195 - ) 1
23 90-0810 Bolt, 1/2 X 1-1/4 1
24 90-0832 Bolt, 1/2 X 4 2
25 95-08 Flat Washer, 1/2 SAE 2
26 42-429 Link, Height Adj. Middle Left (Serial No. 1001 - 1194) 1
42-446.17 Link, Height Adjust Left Middle (Serial No. 1195 - ) 1
27 62-697 Frame, Roller (Serial No. 1001 - 1194) 1
62-728 Frame, Rear Roller (Serial No. 1195 - 5456) 1
62-870.17 Frame, Rear Roller (Serial No. 5457 - ) 1
28 50-067 Roller, Rear (Serial No. 1001 - 1194) 1
50-079 Roller, Rear (Serial No. 1195 - ) 1
29 50-105 Nylon Roller, Front (Serial No. 3332 - ) 1
50-007 Roller, Front (Serial No 1001 - 3331) 1
85-B11 Bearing, 3/4" Wood RollerSerial No 1001 - 3331) 2
30 50-074 Axle, Anti-Scalp Roller 1
31 90-0648 Bolt, 3/8 X 6 1
32 99-E12 Flange Nut, 5/16 4
33 55-FB16016 Bearing, 160 Flange 1" 2
34 97-0508 Carriage Bolt, 5/16 X 1(Serial No. 1001 - 2010) 4
90-0510 Bolt, 5/16 x 1-1/4 (Serial No. 2011 - 5456) 4
99-K62 Bolt, Flange 5/16 x 1-1/4 (Serial No. 5457 - ) 4
35 64-663 Bushing, Adjuster Link Thin (Serial No. 1195 - ) 4
36 90-0614 Bolt, 3/8 X 1-3/4 1
37 94-06 Flat Washer, 3/8 USS (Serial No. 1195 - ) 2
38 64-662 Bushing, Adjuster Link Thick (Serial No. 1195 - ) 2
39 64-662 Bushing, Adjuster Link Thick (Serial No. 1195 - ) 1
40 99-K11 Bolt, Flange 3/8 X 3/4 1
41 64-807 Spacer (Serial No. 1001 - 3246) 2
64-845 Shield, Bearing (Serial No. 3247 - ) 2
42 29-045 Grease Fitting, 1/4 45-Deg. 1
43 64-799 Washer, 13/32 x 1-9/32 6
