Steiner MD460 Owner/Operator's Manual & Illustrated Parts List

09-254B 6 - 19 rev 3/03
PARTS section 6
Parts List for Figure 5
Ref Part No. Description Quantity
1 REF Main Deck Weldment 1
2 40-329 Idler Arm (48"/ 60") 1
40-330 Idler Arm (72") 1
3 99-E20 Flange Nut, 1/4 2
F1002 Jam Nut, 1/4 (72” only) 1
4 56-055-02 Chain, #2 Straight Link 2" Long (48") 1
56-055-04 Chain, #2 Straight Link 4" Long (60"/ 72") 1
5 90-0410 Bolt, 1/4 x 1-1/4 1
6 41-092 Spring, Ext. 1 OD x 4.5 Long (60") 1
41-052 (REF) Spring, Ext. .875 OD x 6.75 Long (48")(See Fig. 1, Ref. 3)
41-051 (REF) Spring, Ext. .875 OD x 6.75 Long (72")(See Fig. 1B, Ref. 3)
7 64-966 Pivot Stop Pin 1
8 92-08 (REF) Nut, 1/2 (See Fig. 1, Ref. 15)
9 96-08 (REF) Lock Washer, 1/2 (See Fig. 1, Ref. 16)
10 95-08 (REF) Flat Washer, 1/2 SAE (See Fig. 1, Ref. 17)
11 83-012 (REF) Idler, “V” 1/2" ID x 4-1/2" OD (See Fig. 1, Ref. 12)
12 90-0814 (REF) Bolt, 1/2 x 1-3/4 (See Fig. 1, Ref. 19)
13 90-0608 (REF) Bolt, 3/8 x 1 (See Fig. 1, Ref. 30)
14 64-799 (REF) Washer, 13/32 ID x 1-9/32 OD (See Fig. 1, Ref. 31)
15 85-B29 (REF) Bushing, .406 x .740 x .258 Thick (See Fig. 1, Ref. 18)
16 90-0608 Bolt, 3/8 x 1 1
17 64-799 Washer, 13/32 ID x 1-9/32 OD 1
18 64-967 Flip-Up Latch 1
19 41-013 Spring, Ext. 0.50 x 1.938 1
20 64-965 Front Lift Arm Stop 1
21 99-E20 Flange Nut, 1/4 8
22 99-K26 Bolt, Flange 1/4 x 3/4 8
23 64-968 Flip-Up Deck Brace, Left (60"/ 72") 1
64-970 Flip-Up Deck Brace, Left (48") 1
24 64-969 Flip-Up Deck Brace, Right (60"/ 72") 1
64-971 Flip-Up Deck Brace, Right (48") 1
25 02-PP0524 Presto Pin, 5/32 x 2-5/16 1
26 64-974 Bolt On Handle, LH (48") 1
64-976 Bolt On Handle, LH (60") 1
64-972 Bolt On Handle, LH (72") 1
27 64-998 Hold Down, Roller Frame (72”)(Serial No. 2592 - ) 1
28 99-E13 Flange Nut, 3/8 (48/60”) 2
99-E13 Flange Nut, 3/8 (72”)(Serial No. 1001 - 2591) 3
99-E13 Flange Nut, 3/8 (72”)(Serial No. 2592 - ) 5
29 64-973 Bolt On Handle, RH (48") 1
64-975 Bolt On Handle, RH (60") 1
64-972 Bolt On Handle, RH (72") 1
30 95-10 (REF) Flat Washer, 5/8 SAE (See Fig. 2, Ref. 15)
31 50-007 (REF) Roller, Front (See Fig. 2, Ref. 29)
32 50-062 (REF) Axle Tube, Caster Wheel (See Fig. 2, Ref. 16)
33 99-K58 Bolt, 3/8 x 3/4 Button Head 2
34 90-0652 Bolt, 3/8 x 6-1/2 1
35 99-K11 Bolt, Flange 3/8 x 3/4 (72”)(Serial No. 2592 - ) 2
36 99-K82 Bolt, Flange 1/2 x 2 1
37 99-B12 Washer, 1/4 x 17/32 x 1-1/8 (used to modify older models) 2
38 99-E37 Flange Nut, 1/2 1
39 62-858.17 (REF) Arm, Right Hitch (See Fig. 3, Ref. 11)
40 64-939 (REF) Anchor, Lift Arm Left (See Fig. 3, Ref. 9)
64-938 (REF) Anchor, Lift Arm Right (See Fig. 3, Ref. 7)
41 95-06 Flat Washer, 3/8 SAE 1
42 94-04 Flat Washer, 1/4 USS 6
43 90-0614 (REF) Bolt, 3/8 x 1-3/4 (See Fig. 1B, Ref. 19)
44 94-06 (REF) Flat Washer, 3/8 USS (See Fig. 1B, Ref. 16)
45 83-034 Idler, “V” 3/8"ID x 5" OD 1
46 99-A06 Locknut, Stover 3/8 1
