100
THOR 40/60 H
COD. 6983000010
STEL s.r.l. – Via del Progresso n° 59 – 36020
Loc. Castegnero (VICENZA) - ITALY
TEL. +39 444 639525 (central.) – +39 444 639682 (comm.)
FAX +39 444 639641 – E-mail: stel @ stelgroup.it
http: www.stelgroup.it
11.1- RECOMMANDATIONS GÉNÉRALES
11.2- MODALITÉS DE COMMANDE
Pour commander les pièces de rechange au S.A.V. agréé,
consulter le TAB. 5 et la FIG. 1.
PIÈCES DE RECHANGE
LES PIÈCES RECHANGE D’ORIGINE POUR LES ÉVENTUELS
REMPLACEMENTS DOIVENT ÊTRE DEMANDÉES
EXCLUSIVEMENT AU SERVICE APRÈS-VENTE AGRÉÉ
(DEMANDER À STEL SRL LE NOM DU S.A.V. LE PLUS PROCHE).
FRANÇAIS
IL EST ABSOLUMENT INTERDIT DE REMPLACER UN
COMPOSANT DE LA MACHINE AVEC UNE PIÈCE DE RECHANGE
QUI NE SERAIT PAS D‘ORIGINE.
PART LIST THOR 40H 1F 230V COD. 60034 (FIG. 1 A)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Poignée
Oeillet
Panneau latéeral
Plan supérieur
Suport
Sélecteur d.29
Bouton
Tableau
Plaque frontale
Logique µP
Support PCB HF-R
Bornier à 5 pôles
Sélecteur
Trasformateur
pour
HF
Unité XL
Accouplement
Passe-câble torche
Plaquette douilles
Prise fixe CX30
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
Plaquette logo
Base
Deuxiéme
PCB d’aliment.
Relais pilote
Câble d’alimentation
Thermostat 90°
Ventilateur motorisé
Transformateur auxiliaire
Protection
Filtre régulateur de s’air
Premiére PCB d’aliment.
Plaque latéerale
PCB HF
Tuyau
Electrovanne
Pressostat
Thermostat 80°
Filtre ligne
Passe-câble
Microinterrupteur
Protection pour filtre reg.
6611200000
4226100000
6202000000
6201900000
-
6313100000
6620800000
6623100000
6257200000
6635500000
612870000L
6258400000
6406600000
6465000000
613950000L
613070000L
-
6651800000
6635900010
6428000000
6687400010
6201800010
619830001L
610900000L
6164900000
6577400000
6418200000
6501930000
6609800000
6305200000
619250000L
6629300000
618190005L
6616000000
6413000000
6403200000
6577500000
617330000L
6606100000
6413200000
6202200000
THOR 40/60 H
COD. 6983000010
49
STEL s.r.l. – Via del Progresso n° 59 – 36020
Loc. Castegnero (VICENZA) - ITALY
TEL. +39 444 639525 (central.) – +39 444 639682 (comm.)
FAX +39 444 639641 – E-mail: stel @ stelgroup.it
http: www.stelgroup.it
4.1- DELIVERY OF THE MACHINE
The package contains:
- N. 1 THOR generator.
- N. 1 torch
- N. 1 instructions manual.
- N. 1 guarantee
Check that all the material listed above is included in the package.
Inform your distributor if anything is missing.
Check that the generator has not been damaged in transport. If you see
any sign of damage, consult the COMPLAINTS section for instructions.
Before working with the THOR, read the SAFETY and USE section of
this manual.
4.2- COMPLAINTS
Complaints for damage during transport: If your equipment is
damaged during transport, send a complaint in writing to the carriers.
Complaints for faulty goods: All the equipment shipped by STEL SRL
has been subjected to strict quality control.
However, if your equipment does not work correctly, consult the
TROUBLESHOOTING section in this manual.
If the fault persists, consult your authorised dealer.
4.3- LIFTING AND HANDLING
Once the packaging has been removed, the machine may be lifted and
handled manually by means of the handle on the top. (FIG. 2-Ref. 1).
During transport the operator must take care not to knock the machine
accidentally against persons, animals or things.
4.4- POSITIONING
The machine must be positioned on a surface that ensures stability, far
from sources of heat, dripping water, inflammable and/or explosive
material.
TRANSPORT
IT IS OBLIGATORY TO ENSURE THAT, DURING CUTTING, THE REAR
AND THE SIDES OF THE MACHINE ARE FREE FROM OBSTACLES AND
AT A MINIMUM DISTANCE OF 1000 MM. TO GUARANTEE
CIRCULATION OF THE AIR PROVIDED BY THE INTERNAL FAN.
ENGLISH
