TMAX™ Owner’s Manual | Page 9
TMAX1/30K/16K-9 Mounting Kit - Chevy - PN 101362
PN 101362
01 C1025 4CAP SCR 0.63-11X2.00 HHGR8
04 24046 1BRKT BODY MNT 60 CA T1 9 LF FRT PC BLACK
03 24868 12NUT 0.63-11 HHGR8 NYLOC
02 C5902 24WASHER 0.63 SAE FLAT YELLOW GR8
05 24047 1BRKT BODY MNT 60 CA T1 9 RF FRT PC BLACK
06 109752 1SPACER 0.19 BODY MNT T1-9 LF DC5500
07 109753 1SPACER 0.19 BODY MNT T1-9 RF C5500
08 84053 8CAP SCR 0.63-11X2.25 HHGR8
ITEM PART No. QTY.DESCRIPTION
17.13
8
8
1
3
2
2
BODY MOUNT ON FRONT OF SUBFRAME
BODY MOUNT ON REAR
OF SUBFRAME
6
7
2
3
CENTER OF AXLE
TO REAR OF
FRONT MOUNT
