TMAX™ Owner’s Manual
TMAX1-13 & TMAX1/30K/16K-11 Mounting Kit - Chevy - PN 101361
41.13
1
2
7
7
4
4
4
BODY MOUNT ON FRONT OF SUBFRAME
BODY MOUNT ON REAR
OF SUBFRAME
6
RETAIN CHASSIS BOLTS
FOR BODY INSTALLATION
TYP 4
3
4
4
5
4
5
7
4
5
CENTER OF AXLE TO
REAR OF FRONT MOUNT
PN 101361
01 13254 1BRKT BODY MNT FRONT LF PC BLACK
04 C5902 24WASHER 0.63 SAE FLAT YELLOW GR8
03 C1025 4CAP SCR 0.63-11X2.00 HHGR8
02 13251 1BRKT BODY MNT FRONT RF PC BLACK
05 24868 12NUT 0.63-11 HHGR8 NYLOC
06 109051 2SPACER FRONT C5500 2019
07 84053 8CAP SCR 0.63-11X2.25 HHGR8
ITEM PART No. QTY.DESCRIPTION
