16
STEPCRAFT
210
STEPCRAFT
300
STEPCRAFT
420
STEPCRAFT
600
STEPCRAFT
840
6063 T66) with
roller guides
6063 T66) with
roller guides
6063 T66) with
roller guides
6063 T66) with
roller guides
6063 T66) with
roller guides
Drive
Stepper motors
Stepper motors
Stepper motors
Stepper motors
Stepper motors
Tool holder
Ø 43 mm / 1.69
inch (optional
smaller
diameters)
Ø 43 mm / 1.69
inch (optional
smaller
diameters)
Ø 43 mm / 1.69
inch (optional
smaller
diameters)
Ø 43 mm / 1.69
inch (optional
smaller
diameters)
Ø 43 mm / 1.69
inch (optional
smaller
diameters)
Overall size
340 mm x 345
mm x 350 mm
13.39 x 13.58 x
13.78 inch
430 mm x 350
mm x 410 mm
16.93 x 13.78 x
16.14inch
550 mm x 450
mm x 510 mm
21.65 x 16.93x
20.08 inch
730 mm x 570
mm x 510 mm
28.74 x 22.44 x
20.08 inch
970 mm x 750
mm x 510 mm
38.19 x 29.53 x
20.08 inch
Weight
11 kg
24.25 lbs
13 kg
28.66 lbs
15.0 kg
33.07 lbs
19,0 kg
41.89 lbs
31 kg
68.34 lbs
Machine table
HPL
HPL
HPL
HPL
HPL
Color
STEPCRAFT
orange,
Aluminum,
white
STEPCRAFT
orange,
Aluminum,
white
STEPCRAFT
orange,
Aluminum,
white
STEPCRAFT
orange,
Aluminum,
white
STEPCRAFT
orange,
Aluminum,
white
Input voltage
(AC)
100 – 240 V
100 – 240 V
100 – 240 V
100 – 240 V
100 – 240 V
Output voltage
(DC)
19 V
30 V
30 V
30 V
30 V
Power
consumption
90 W
90 W
90 W
90 W
90 W
Interface
USB or parallel
USB or parallel
USB or parallel
USB or parallel
USB or parallel
* For constructional reasons the travel distance of the Z-axis is getting reduced at the end positions of the X-
axis by 10 mm / 0.39 inch.
6.4 SPARE PARTS
All parts of the machine and control can be purchased individually as spare parts.
Please contact us directly. Please find our contact data on item 10.3 of these instructions.
Please keep your machine data ready at hand when ordering spare parts.
6.5 PIN ASSIGNMENT CHARTS OF UNIT CONTROL / OPTIONAL MODULES
6.5.1 PARALLEL PORT LPT-ADAPTER (X1)
Connection of the computer to the unit control via parallel module (optional):
Signal
Pin
Relay 1
1
Direction X
2
Step X
3
Direction Y
4
Step Y
5
Direction Z
6
Step Z
7
Direction 4th axis
8
Step 4th axis
9
Tool length sensor
10
Emergency stop
11
Reference switch X/Y/Z
12
Reference switch 4th axis
13
