Steren BOC-2136 - Rear Panel

2
1. Connect the satellites into the AUDIO OUPUT connectors and to the DC 5V output.
2. Connect the power cord into an electrical outlet.
REAR PANEL
INPUT
ANT
OUTPUT
DC 5V
POWER
ON
OFF
R
R L
L
ON/OFF switch
Power cord
Antenna
RCA auxiliary
DC 5V output
Satellites
(Right/Left)
CONNECTION
INPUT
ANT
OUTPUT
DC 5V
POWER
ON
OFF
R
R L
L
R L
The DC 5V connector power the light of the satellites
