Sterlco 6017 Series - User Manual

Questions and Answers

B
Barbara RobbinsAug 2, 2025
Why does my Sterlco Temperature Controller have temperature fluctuations?
- M
  Maureen BrownAug 3, 2025
  Temperature fluctuations in your Sterlco Temperature Controller can occur due to several reasons: * Undersized connectors or water lines: Increase their size. * Long connecting lines: Shorten them by moving the unit closer to the mold. * Serpentine flow through the mold: Connect lines for parallel flow. * Blocked line in the mold: Check and clean the mold for any obstructions. * Quick disconnect fitting with check valve: Replace the fitting or valve. * Carbon build-up: Clean or replace affected piping and replace the fluid. * Faulty Sterlco TCU: Check the unit by opening the manual bypass to see if the TCU controls the set point temperature. * Reversed probes: Switch the Return and Delivery probes.
C
Cynthia HahnAug 7, 2025
What to do if Sterlco Temperature Controller unit overheats and is unable to cool?
- K
  kristen38Aug 7, 2025
  If your Sterlco Temperature Controller unit is overheating and unable to cool, check the following: * Ensure the water supply to the unit is turned ON; open the water supply if it's off. * Clear any blockage in the water drain line and eliminate excessive back pressure. * Inspect the heat exchanger tubes for lime deposits and clean or replace them as needed. * Test the solenoid valve by switching to Manual Cool mode and listen for its operation; replace it if faulty.
A
Amy DavisAug 11, 2025
What to do if my Sterlco Temperature Controller unit does not heat properly and can not achieve set point?
- C
  Chad WeberAug 11, 2025
  If your Sterlco Temperature Controller unit isn't heating properly or can't reach the set point, consider these potential causes: * Loss of fluid: Check all lines, connections, and fittings for leaks. * Vent valve open: Allow the vent timer to run out, or check the valve operation when the unit is cold by opening the fill port. * Faulty or dirty solenoid valve: Switch to Manual Cool mode several times to flush the valve; if the leak continues, disconnect the power, turn off the water supply, and clean or replace the solenoid. * Degraded fluid: Drain and replace the fluid.
E
Elizabeth BrooksAug 15, 2025
What causes a rapid drop in pressure or no pressure in Sterlco Temperature Controller?
- T
  Timothy JohnsonAug 16, 2025
  A rapid drop in pressure or no pressure in your Sterlco Temperature Controller can be caused by: * Leaks in connecting lines: Inspect and replace any faulty lines or connections. * Air in circulating lines: Perform the venting sequence. * Low fluid: Check the fluid level and add fluid if needed. * Vent solenoid open: Allow vent timer to run out; or, check valve operation when unit is cold by opening the fill port. * Pump running in reverse: Check the motor and rewire if necessary. * Pump repair/adjustment needed: Adjust head spacing or replace worn pump components. * V belt broken/worn: Replace as required.
J
jphillipsAug 20, 2025
How to fix Sterlco Temperature Controller when the unit does not heat?
- J
  Joseph SingletonAug 20, 2025
  If your Sterlco Temperature Controller unit isn't heating, check these possible causes: * Defective heater contactor: Perform a visual inspection of the coil and contacts; repair or replace any defective contactors. * Defective immersion heater: Check the resistance on all three legs of the heater with an ohmmeter; if they are not all equal, contact the factory for a replacement heater. * Heater burnout: Check the heater tank for scorched or discolored paint and check the resistance on all three legs of the heater with an ohmmeter; replace the heater as needed.
S
Sharon FieldsAug 25, 2025
What to do if Sterlco Temperature Controller unit does not heat?
- S
  Steven MillerAug 25, 2025
  If your Sterlco Temperature Controller is not heating, check if: * The controller heater output is open: Check the heater output with an ohmmeter to ground. It should read in the mega-ohm range. Infinite or zero readings indicate a defective output. * The Y strainer is clogged: Clean the Y strainer.
W
Wanda CurryAug 28, 2025
Why is my Sterlco Temperature Controller pump noisy?
- S
  Susan CarterAug 28, 2025
  A noisy pump in your Sterlco Temperature Controller can be due to: * Water in the fluid: Drain water from the low point in the piping, or boil the water off. * Severely degraded fluid: Drain and flush the system, then replace the fluid.

Summary

Safety Considerations

General Safety Practices

Essential safety rules for unit operation and maintenance.

System Warnings and Cautions

Critical alerts for electrical, purging, and tank safety.

General Information

Introduction

Overview of the Sterling/Sterlco 6017 Series hot oil temperature control unit.

Necessary Documents

Lists essential documents for safe installation, operation, and maintenance.

Models Covered

Details the 6017 Series models and identification on the serial tag.

Standard Features

Lists the core functionalities and components included in the unit.

Available Options

Describes optional add-ons and configurations for the 6017 Series units.

Feature Descriptions

Explains key components like immersion heaters, heater tank, pump, and Ful-Flo valve.

Shipping Information

Unpacking and Inspection

Procedures for checking the unit's condition upon arrival.

Handling Shipping Damages

Steps to take if the unit is damaged during transit.

Shipment Discrepancies

Actions for incomplete or incorrect shipments received.

Returns Process

Guidelines for returning products to Sterling, Inc.

Installation

Installation Work Rules

Safety and procedural guidelines for installing the unit.

Installation Requirements

Conditions for unit placement, ventilation, and clearance.

Connecting Piping

Details on connecting process, cooling water, and vent piping.

Making Electrical Connections

Instructions for safe and proper electrical hookup of the unit.

Startup Preparations

Starting the Unit

Step-by-step guide for initial unit startup, including manual and autovent.

Shutting Down the Unit

Procedures for safely powering down and cooling the unit.

Returning Fluid to the Tank

Steps to drain process lines back into the reservoir tank.

Using Controls and Indicators

Microprocessor Controller Overview

Explanation of the M2B controller's function and operation.

Controller Panel Components

Identification and description of controller displays and indicators.

Controller Key Operations

Guidance on navigating and operating the controller using its buttons.

Control Panel Switches

Descriptions of the unit's physical switches and their functions.

System Status Board Indicators

Explanation of status lights for monitoring system performance.

Preventive Maintenance

Periodic Checks

Recommended daily, monthly, quarterly, and semi-annual inspections.

Routine Servicing

General maintenance procedures for keeping the unit in good working order.

Draining for Storage

Instructions for preparing the unit for long-term storage.

Corrective Maintenance

Procedures for repairing common issues, focusing on pumps and seals.

Troubleshooting

Common Issues and Solutions

Guide to diagnosing and resolving operational problems.

Sterlco 6017 Series Specifications

General

Series	6017
Mounting	Panel Mount
Type	Temperature Controller
Sensor Type	Thermocouple (J, K, T), RTD (Pt100, JPt100)
Input Types	Thermocouple, RTD
Control Outputs	Relay, SSR drive, analog (4-20mA, 0-20mA)
Display	LED, dual display
Power Supply	100-240VAC
Enclosure Rating	NEMA 4X (IP66)
Alarm Outputs	2 programmable alarms (relay or open collector)
