POS PART NUMBER DESCRIPTION NUM
11 8341-754401-00 Vibration reduction
pad
2
12 A043022-033-00 Connection Wire
Assembly
1
13 A043022-034-00 Left housing assembly 1
13.1 A043022-001-00 Left housing 1
13.2 A043022-002-00 Left overlay cover 1
14 8SJGB40-16D Self tapping screw 12
15 8331-534802 Knife set 1
16 306000048 Lubricating oil 18g
17 242-1009 Thread glue 0.3g
18 254-1003 Tin wire 1.5g
8.4 TROUBLESHOOTING
DANGER ! Risk of injury due to electric shock.
Warning ! Before any trouble shooting, switch o the product.
Problems Probable causes Solutions
Qualifi cation
required
Product does
not start
Battery is not secure
To secure the battery pack,
make sure the latches on the
top of the battery pack snap
into place
No speci c
quali cation is
required
Battery is not charged
Charge the battery pack
according to the instructions
included with your model
Power/speed switch is in the
OFF position
Press the on/o switch
Battery pack not properly
attached
Attach properly
On/o switch not set on ON
position
Refer to chapter “Start the
product”
Product does
not reach full
power
Battery pack capacity too
low
Charge battery pack
No speci c
quali cation is
required
Air vents are blocked Clean the air vents
Vibration
or noise is
excessive
Bolts/nuts are loose Tighten bolts/nuts
No speci c
quali cation is
required
Blade is dull/damaged
Have it replaced with a new
one
Specialist
electrician
