Replace chain when cutters are too worn to sharpen or when chain breaks. Only use replacement chain
noted in this manual. Always include new drive sprocket when replacing chain. This will maintain proper
driving of chain.
1. Place the saw body on a rm and level surface.
2. Rotate the bar adjust locking knob anticlockwise to remove the cover from the saw’s body.
3. Wearing protective gloves, wrap the saw chain around the chain bar, making sure that the teeth are
aimed in the direction of rotation. The chain should be properly set in the slot running along the entire
outside edge of the chain bar.
4. Place the saw chain around the sprocket) while lining up the slot in the chain bar with the internal bolt
at the base of the saw and the chain tensioning pin in the chain bar’s pin hole. The chain tensioning pin
may need adjustment to properly align with the hole in the chain bar. Use the chain tensioning wheel to
adjust its location until it ts in the chain bar.
5. Turn the chain tensioning wheel to preliminarily tighten the chain bar enough that it stays in place.
While holding the bar still, place the cover back onto the saw. Make sure the tab properly lines up with the
slot on the body of the saw. Lock the cover in place with the cover locking knob by turning it clockwise
until it engages. Adjust the chain tension.
