8.EXPLODED VIEW WITH PARTS LIST
POS DESCRIPTION POS DESCRIPTION POS DESCRIPTION
1 End cap assy 21-6 Bearing 48-1 Nut
1-1 Pressing knob 21-7 Nut 48-2 Wind deector
1-2 Adjustment knob 22 Cable/plug 48-3 Nut
1-3 End cap 23 Cable sleeve 48-4 Motor gear
1-4 Spring 24 Left housing 48-5 Gear sleeve
2 Rotational wheel assy 25 Pressing plate 48-6 Bearing
2-1 Clip 26 Terminal board 48-7 Rotor
2-2 Pressing plate 27 Switch button 48-8 Bearing
2-3 Rotational wheel 28 Spring 48-9 Stator
2-4 Plate 29 Spring 48-10 Sleeve
2-5 Sleeve 30 Self-locking button 48-11 Motor back bracket
3 Bar 31 Capacitor 48-12 Carbon brush & holder assy
4 Seal ring 32 Screw 48-13 Connection wire
5 Screw 33 Switch 48-14 Screw
6 Chain 34 PCB 48-15 Screw
7 Bar sleeve 35 Rod 49 Motor cover
8 Seal ring 36 Pressing plate 50 Decoration cover
9 Screw 37 Fixing plate 51 Oil tank assy
10 Screw 38 Spring 51-1 Oil tube
11 Gasket 39 Switch rod assy 51-2 Sealing ring
12 Buer board 39-1 Pin 51-3 Spring
13 Right housing 39-2 Swith rod 51-4 Oil tank
14 Screw 40 Gasket 51-5 Valve
15 Screw 41 Oil nozzle assy 52 Rubber pad
16 Sprocket 42 Oil pump assy 53 Oil tank cap assy
17 E-ring 42-1 Turbine gear 53-1 Anti-lost ring
18 Spring 42-2 Turbine 53-2 Seal ring
19 Brake plate 42-3 Oil pump 53-3 Oil tank cap
20 Anti-dust cover 42-4 Spring 53-4 Oil tank cap cover
21 Output shaft assy 43 Oil tube 54 Female terminal
21-1 Bearing 44 Screw 55 Connection wire
21-2 Output shaft 45 Front handle 56 Male terminal
21-3 Brake torsion spring 46 Chain brake 57 Copper strip
21-4 Axle sleeve 47 Screw 58 Heat-shrinkable tube
21-5 Output shaft gear 48 Motor assy 59 Connection wire
238
EN
