STERWINS PBC2-52B-AB.2 Legal And Safety Instructions

4. TECHNICAL DATA
274
EN
Model
PBC2-33B-
AB.2
PBC2-43B-
AB.2
PBC2-52B-
AB.2
Engine displacement 32.6 cm
3
42.7 cm
3
51.7 cm
3
Max. engine power, in accordance with ISO
8893
1.0 kW 1.25 kW 1.5 kW
Mass (without fuel, cutting attachment
and harness)
6.99 kg 7.65 kg 7.7 kg
Maximum rotational frequency of the
spindle
Brush cutter: 8250 min
-1
; Grass trimmer:
7125min
-1
Engine idling speed range
3100±400 min
-1
Fuel tank volume 750 cm
3
850 cm
3
Sound pressure level at operator position
(in accordance with ISO 22868)
93.9 dB(A) 94.5 dB(A) 94.3 dB(A)
Uncertainty K 3 dB(A)
Sound power level (in accordance with ISO
22868)
110.6 dB(A) 111.3 dB(A) 110.8 dB(A)
Uncertainty K 3 dB(A)
Guaranteed sound power level 113 dB(A)
Vibration (in accordance
with ISO 22867)
left handle 4.48 m/s
2
4.80 m/s
2
4.91 m/s
2
right handle 4.33 m/s
2
4.57 m/s
2
4.66 m/s
2
Uncertainty K 1.5 m/s
2
Recommended
cutting attach-
ment
Recommended
cutting attach-
ment guard
Type Cutting
width
(mm)
Thickness of
blade/ diameter
of cutting line
(mm)
Blade centre
hole diameter
(mm)
Blade
without extended
guard
3 teeth, single
piece, metal
255 1.6 25.4
Trimmer head with extended
guard
Non-metallic
Flexible cutting
line
430 2.4 N/A
Warning Use your trimmer/brush cutter equipped with the recommended
cutting attachment and guard. Non-observance will result in the risk of
serious injury or death to oneself or others.

STERWINS PBC2-52B-AB.2 Specifications

General

Brand	STERWINS
Model	PBC2-52B-AB.2
Category	Lawn Mower
Language	English
