3-17 Description – S25UXi
No
Parts
Parts No.
Q’TY
Remark
1
Interface board
201040
1 ea
Rev. L
2
Wire_I005
301093
1 ea
3
Wire_I004
301092
1 ea
4
Wire_I003
301091
1 ea
5
S_Scaler Comm Cable
300337
1 ea
6
Wire_D005
301088
1 ea
7
Wire_D003
301043
1 ea
8
Wire_D002
301087
1 ea
9
Wire_D006
301089
1 ea
10
Wire_P001
301017
1 ea
11
Membrane switch
300362
1 ea
12
Wire_D001
301086
1 ea
13
Multi board
201126
1 ea
Rev. D
14
iPOD Cable
200066
1 ea
15
Wire_S003
301096
1 ea
16
Wire_S006
301098
1 ea
17
Scaler board
300333
1 ea
18
Wire_S001
301095
1 ea
19
HDMI Cable 1.5m
301044
1 ea
20
Wire_S004
301097
1 ea
21
Wire_S007
301099
1 ea
22
Wire_S009
301099
1 ea
23
LCD Inverter board
300335
1 ea
24
15” LCD Panel
301629
1 ea
25
Wire_S008
301100
1 ea
26
Fast track board
201032
1 ea
Rev. C
27
Membrane Fast track
301080
1 ea
28
Wire_H001
301064
2 ea
29
Touch HR Sensor
301067
8 ea
30
EXT. Input board
201015
1 ea
Rev. 02
31
Wire_P005
301020
1 ea
32
Power board
201006
1 ea
Rev. 06
33
Wire_P003
301018
1 ea
34
Wire_P004
301019
1 ea
35
Hybrid Generator
301011
1 ea
36
Comm. board
201047
1 ea
Rev. 01
37
Wire_I006
32Q1-MS171
1 ea
38
Touch screen board
200087
1 ea
39
15” Touch panel
300329
1 ea
