No. Parameter Setting range Standard System value
1 ENTER CODE 0000 to 9999 1000
2 LANGUAGE German
3 CONTRAST – 10 to + 10 0
4 DISPLAY ACTUAL RETURN
5 EMERGENCY OP ON / OFF OFF
6 COOLING OPERATION * ON / OFF OFF
7 HEAT-UP PROGRAM ON / OFF OFF
8 SUMMER OP ON / OFF ON
9 PUMP CYCLES ON / OFF OFF
10 BUFFER PRIMARY PUMP – CONSTANT RUN ON / OFF ON
11 FIXED TEMP OFF / °C OFF
12 SOURCE Ethylene glycol
13 MIN SOURCE T – 10 °C to 10 °C -9°C(triplephase)
-5°C(singlephase)
14 MAX RET TEMP 20 °C to 55 °C 50 °C
15 MAX HTG FL TG 20 °C to 65 °C 60 °C
16 HP SENSOR 38 bar to 40 bar 38 bar
17 MIXER TEMPERATURE MAX 20 °C to 90 °C 50 °C
18 MIXER DYNAMIC 30 - 240 100
19 FROST PROTECTION – 10 °C to 10 °C 4 °C
20 SELECT REM CON Heating circuit 1
21 FE CORRECTION - 5 K to + 5 K 0
22 ROOM INFLUENCE 0 to 20 5
23 LIMIT TEMPERATURE HEATING OFF to 30 °C OFF
24 DUAL-MODE TEMPERATURE - HEAT SOURCE 2 – 20 °C to 30 °C – 20 °C
25 LIMIT TEMPERATURE DHW OFF to 30 °C OFF
26 DUAL-MODE T DHW – 20 °C to 30 °C – 20 °C
27 DHW ECO ON / OFF OFF
28 DHW HYSTERESIS 1 °C to 10 °C 3 °C
29 DHW CORRECTION 1 K to 5 K 3 K
30 PASTEURISATION ON / OFF OFF
31 CONTROLLER DYNAMICS 1 – 30 20
32 IDLE TIME AFTER SWITCHING THE COMPRESSOR OFF 1 to 120 min 20 min
33 RES IDLE TIME
34 SINGLE PHASE ON / OFF ON
35 QUICK START
36 RELAY TEST
37 LCD TEST
38 FAULT LIST
39 WPMi SOFTWARE ISSUE
40 ANALYSIS
41 DIAGNOSTIC
42 RESET HP
43 RUNTIMES
* May only be adjusted for WPF 5-16 in conjunction with WPAC 1.
2.15 Commissioning report
The controller should be in standby mode during commissioning. This prevents an uncontrolled heat pump start. Please remember to reset
the system into its last operating mode.
