61
ENGLISH
EN
can be found in the service log and the actions are
described under “4 STARTING AND OPERA-
TION” as well as below.
Servicing carried out at an authorised workshop
guarantees professional work using genuine spare
parts.
At each basic service and intermediate service car-
ried out at an authorised workshop, the service log
is stamped. A service log presenting these services
is a valuable document that improves the ma-
chine’s second-hand value.
5.2 Preparation
All service and all maintenance must be carried out
on a stationary machine with the engine switched
off.
Prevent the machine from rolling by al-
ways applying the parking brake.
Stop the engine.
Prevent unintentional starting of the
engine by disconnecting the spark plug
cable(s) from the spark plug(s) and re-
moving the ignition key.
5.3 Tyre pressure
Adjust the air pressure in the tyres as follows:
Front: 0.6 bar (9 psi).
Rear: 0.4 bar (6 psi).
5.4 Changing engine oil
This section contains tables covering the different
engines that are included in STIGA’s Pro range. To
facilitate reading, mark the data that applies to the
relevant machine/engine.
5.4.1 Change intervals
The table below states hours of operation and cal-
endar months. Carry out the relevant action at
whichever occurs first.
Change the oil more frequently if the engine has to
operate in demanding conditions or if the ambient
temperature is high.
5.4.2 Engine Oil
Use syntetic oil according to the table below.
Use oil without any additives.
Do not fill with too much oil. This can cause the
engine to overheat.
Change oil when the engine is warm.
The engine oil may be very hot if it is
drained off directly after the engine is
shut off. Therefore allow the engine to
cool a few minutes before draining the
oil.
1. Attach the clamp on the oil drainage hose. Use
a polygrip or similar. See fig. 15-17:Y.
2. Move the clamp up 3-4 cm on the oil drainage
hose and pull out the plug.
3. Collect the oil in a collection vessel.
NOTE! Do not spill any oil on the drive belts.
4. Hand in the oil for disposal in accordance with
local provisions.
5. Install the oil drainage plug and move the clamp
back so that it clamps above the plug.
6. Remove the dipstick and fill with new oil.
Oil quantity:
7. After filling up the oil, start the engine and idle
for 30 seconds.
8. Check to see if there is any oil leakage.
9. Stop the engine. Wait for 30 seconds and then
check the oil level in accordance with 4.2.
5.4.3 Oil filter(Power)
The oil filter must be replaced during every second
oil change, i.e. after 200 hours of operation. First
drain the engine oil and install the oil drainage plug
as described above. Then replace the oil filter as
follows:
1. Clean the area around the filter and dismantle
the filter.
2. Place the new filter with the hole facing up-
wards in a vessel.
Machine
1st time Then at
intervals of
Ranger, President,
(B&S)
Hours of operation/
Calendar months
Changing the oil
5 hours
50 hours/
12 months
Excellent (B&S) Hours of operation/
Calendar months
Changing the oil
5 hours
50 hours/
12 months
Changing the filter 100 hours
Power (Kohler) Hours of operation/
Calendar months
Changing the oil - 100 hours
Changing the filter 200 hours
Oil SAE 10W-40
Service class SJ or higher
Machine Oil volume, approx.
No filter
replacement
Filter replace-
ment
Ranger - 1,6 liter
President - 1,6 liter
Power 1,9 liter 2,0 liter
Excellent 1,6 liter 1,7 liter
