0458-724-8601-A
4
English
4 Safety Symbols on the Products
6 Retaining Latch
For switching the blower on and selecting the power
level.
7LEDs
Indicate the unit's power level.
8 Trigger Switch
Switches the motor on and off.
9 Control Handle
Handle for the operator's right hand.
10 Union Nut
Allows simple adjustment of blower tube length.
11 Nozzle
Directs and concentrates the airstream.
12 Blower Tube
Directs the airstream.
13 Cable
For connecting the trigger switch to the motor.
14 Elbow Clamp
For securing the cable in position.
15 Machine Support
For resting the blower on the ground.
16 Intake Screen
Covers the air intake opening and reduces the risk of
contact with the blower fan.
# Rating Plate
Contains electrical information and the product's serial
number.
4.1 Blower
The following safety symbols are found on the blower.
4.2 Battery
The following safety symbols are found on the AR L series
backpack battery.
4 Safety Symbols on the Products
To reduce the risk of injury, follow the specified
safety precautions.
Read and follow all safety precautions in the
instruction manual. Improper use can lead to
serious or fatal personal injury or property
damage.
To reduce the risk of eye injury, always wear
proper eye protection. Power tool noise may
damage your hearing. Always wear proper sound
barriers (ear plugs or ear mufflers) to protect
your hearing, @ 5.4.
To reduce the risk of personal injury from blown
objects, never direct the air flow toward
bystanders or pets, @ 5.6.4.
To reduce the risk of personal injury, keep hair
and loose-fitting clothing away from the air
intake, @ 5.4.
To reduce the risk of injury or property damage
from unintended activation, remove the battery
any time the blower is not in use, @ 6.1.
To reduce the risk of personal injury from
high velocity air flow and blown objects,
keep bystanders at least 17 ft. (5 m) away,
@ 5.6.4.
To reduce the risk of injury, follow the specified
safety precautions.
5m (17 ft)
