15
REPEAT FUNCTION
YES
SLOW
NO
STEP
NO
H.264 SUPPORT
YES
RM,RMVB SUPPORT
SUPPORTS UP TO SD
USB Update SW
YES
4. Connectors and Electrical Parameters.
a) Connector Details:-
IR & Key Board Connector CNB9
NO. Symbol Function Voltages (Stand by) Voltages (ON condition)
1 GND GND 0 0
2 KEY_2 KEY VOLTAGE 3.2V 3.27V
3 GND GND 0 0
4 KEY_1 KEY VOLTAGE 2.57V 2.57V
5 LED_R LED VOLTAGE 0.024V 4.96V
6 5V_SB 5VSB SUPPLY 3.3V 3.3V
7 LED_G LED_G 2.8V 0.024V
8 IR IR Signal 3.2V 3.2V
Power Connector CN26
No
Pin Connection Voltages (Stand by) Voltages (ON Condition)
1 12V 12V 12V
2 12V 12V 12V
3 GND 0V 0V
4 12V 12V 12V
5 GND 0V 0V
6 GND 0V 0V
7 5V 5.03V 5.03V
8 5V 5.03V 5.03V
9 5V_STB 5.08V 5.08V
10 GND 0V 0V
11 SW 3.6V 3.6V
12 GND 0V 0V
13 Back Light ON/OFF 0V 5V
14 Dimming Control 3.6V 3.6V
