17
22 LVTX_B_CH0N 1.1V 1.1V
23 LVTX_B_CH1P 1.1V 1.1V
24 LVTX_B_CH1N 1.1V 1.1V
25 GND 0V 0V
26 GND 0V 0V
27 LVTX_B_CH2P 1.1V 1.1V
28 LVTX_B_CH2N 1.1V 1.1V
29 LVTX_B_CLKP 1.1V 1.1V
30 LVTX_B_CLKN 1.1V 1.1V
31 GND 0V 0V
32 GND 0V 0V
33 LVTX_B_CH3P 1.1V 1.1V
34 LVTX_B_CH3N 1.1V 1.1V
35 LVTX_B_CH4P 1.1V 1.1V
36 LVTX_B_CH4N 1.1V 1.1V
37 3D_EN/AL 0V 0V
38 LVDS_SEL (Rotate) 3.3V (As per panel) 3.3V (As per panel)
39 NC NC NC
40 NC NC NC
a) Critical component list:-
COMPONENT
DESCRIPTION LOCATION
1100043109 CAP,CER,Y5U,400VAC,1KPF,M,10MM
1100043114 DIODE,CHIP,SOT23,LBAV70LT1G,TP
1100043194 IC,OPTO-COUPLER,KP10101B/KPC817B,DIP-4
1100043197 VARISTOR,560V,25AMP,TVR10681KSY
1100043202 THERMISTER,NTC,SCK,6A,2.5E,M,7.5MM,L-5M
1100057520 C,CER,Y5P,1KV,2.2KPF,K,P5MM
1100093176 CAP,CER,275VAC,330KPF,K,15MM
1100098978 C,CER,Y5P,1KV,100PF,K,P5MM
1100105840 IC,CHIP,MQFN76,SiI9687ACNUC,HDMI SW
1100105843 IC,CHIP,SOP8,MX25L3206D/E M2I-12G,NEW
1100106737 C,ELCT,500V,100MFD,M,20X36,P10MM,105°CKM
1100106760 IC,CHIP,EPLQFP,128Pin,TSUMV59XUS-Z1
1100107706 IC,PWM,OB2273A,SOT23-6
1100111347 C,ELCT,250V,33MFD,M,13X20,P5MM,TP,105°C
1100111348 CAP,CBB21,450V,100KPF,K,10MM
1100111349 CAP,CBB21,450V,470KPF,K,15MM
1100111353 PFC INDUCTANCE,GL-2634WH-ER26
1100111354 DIODE,CHIP,DO-201AD,1N5408
1100111356 IC,SOP8,OB6561PCPA-PFC
1100111358 IC,CHIP,SOP8,TP358
1100111361 TRANS,N-MOS,650V/11A MMF60R360P,TO-220MF
1100111362 TRANS,N-MOSFET,650V/4A 4N65L,TO263
1100111363 TRANS,N-MOSFET,800V/8A 8N80-TF1,TO-220MF
