Stihl E 140 - Specifications; 2.1 Motor; 2.2 Gear Drive; 2.3 Cutting Attachment

2.1 Motor E 140 E 160 E 180 C
Type: Universal motor
Rating (kW): 1.4 1.6 1.8
Rated voltage (V): 120; 230 230 120; 230
Frequency (Hz): 60 50 50 60 50
Rated current (A): 11.7 6.4 7.3 15,0 8.2
Fuse (slow-blowing) (A): 15 16 16 15 16
Overload protection: Thermal overload circuit breaker
Type of enclosure: IP 20
Class of protection: II
Coasting brake: Mechanical
2.2 Gear Drive
Type: Straight-toothed ring gear with pinion, single-stage
Output speed with
bar and chain,
off load (idle): 5900 rpm
1)
6300 rpm 6900 rpm
3)
at rated load: 5000 rpm
2)
5400 rpm 5400 rpm
4)
Lubrication: STIHL multipurpose grease
2.3 Cutting Attachment
Chain sprocket: 7-tooth 3/8" Picco
spur sprocket
Chain lubrication: Fully automatic, speed-controlled reciprocating oil pump
Oil tank capacity: 0.20 l (0.4 US pt)
1)
120 V : 6100 rpm
2)
120 V : 4900 rpm
3)
120 V : 6800 rpm
4)
120 V : 5000 rpm
2. SPECIFICATIONS
3
