Stihl FCB-KM User Manual

FCB-KM
English
13
N Turn nut clockwise (left-hand
thread) and remove it.
N Remove the thrust washer.
N Position the blade (7) on the thrust
plate (8).
WARNING
The collar (arrow) must engage the hole
in the blade.
N Fit the thrust washer (4) on the shaft
(9) and block the shaft.
N Screw nut (6) counterclockwise
onto shaft and tighten.
WARNING
If the cup spring (10) on the nut (6)
becomes fatigued, then the nut must be
replaced!
Starting the engine
To start the engine, basically follow the
instructions for use for the KombiEngine
or basic power tool!
N Place the machine on the ground in
a secure position
The blade must not touch the ground or
any other objects – risk of accident!
N Assume a firm stance – possibilities:
standing, bending or kneeling
N Press the machine firmly against
the ground with the left hand – do
not touch the control elements on
the control handle while doing so –
see instruction manual for the
KombiEngine or basic power tool
NOTICE
Do not stand or kneel on the shaft!
WARNING
If the engine is started, the blade may
rotate as soon as the engine is running –
therefore blip the throttle trigger as soon
as the engine is running – the engine
begins to idle.
The other starting procedure is
described in the instruction manual for
the KombiEngine or basic power tool.
Switching off the engine
N see instruction manual for the
KombiEngine or basic power tool
4
10
9
7
7
239BA022 KN
6
8
Starting / Stopping the
Engine
9926BA009 KN
9926BA010 KN
