FS 110, FS 110 R
English
32
Full harness
N Put on the full harness (1).
N Adjust the length of the strap so that
the spring hook (2) is about a hand’s
width below your right hip.
N Balance the trimmer/brushcutter.
Attaching the unit to the harness
The type and style of the harness and
carabiner (spring hook) depend on the
market.
N Attach the carabiner (1) to the
carrying ring (2) on the drive tube.
N Loosen the screw (3).
Balancing the brushcutter
The unit is balanced differently,
depending on the cutting attachment
used.
Proceed as follows until the conditions
specified under "Floating positions"
have been met:
N Adjust the carrying ring.
N Tighten the screw moderately.
N Allow the unit to hang freely.
N Check the position obtained.
Balancing the
Trimmer/Brushcutter
