Stihl FS 131 R User Manual

FS 131, FS 131 R
English
29
Preparations
N Before fueling, clean the filler cap
and the area around it to ensure that
no dirt falls into the tank.
Always thoroughly shake the mixture in
the canister before fueling your
machine.
N Position the machine so that the
filler cap is facing up.
WARNING
To reduce the risk of fire and personal
injuries due to escaping fuel and vapor,
remove the fuel filler cap carefully so
that any excess pressure in the tank can
escape slowly.
Use the proper seasonal gasoline blend,
i.e., winter blend in winter, summer
blend in summer.
Opening
WARNING
After allowing the power tool to cool,
remove the fuel filler cap slowly and
carefully to allow any remaining
pressure build-up in the tank to release:
N While maintaining steady,
downward pressure, slowly turn the
cap approximately a 1/2 turn
counter-clockwise.
N If any significant venting occurs,
immediately re-seal the tank by
turning the cap clockwise to the
closed position. Allow the power
tool to cool further before attempting
to open the tank.
N Turn the cap to the open position
only after the contents of the tank
are no longer under pressure.
N Remove the fuel filler cap.
WARNING
Never remove the cap by turning it
directly to the open position. First allow
the power tool to cool adequately and
then release any residual pressure by
slowly turning the cap approximately
1/2 turn counter-clockwise. Never
attempt to remove the cap while the
engine is still hot or running.
Refueling
Take care not to spill fuel while fueling
and do not overfill the tank – leave
approximately 1/2" (13 mm) air space.
Closing
WARNING
An improperly tightened fuel filler cap
can loosen or come off and spill
quantities of fuel. To reduce the risk of
fuel spillage and fire from an improperly
installed fuel cap, tighten the fuel filler
cap by hand with as much force as
possible:
N If your fuel cap still does not tighten
properly, it may be damaged or
broken. Stop using the power tool
and take it to your authorized STIHL
dealer for repair or replacement.
Fueling
0000-GXX-0476-A0
002BA447 KN
002BA448 KN

Stihl FS 131 R Specifications

General

Power source	Gasoline
Type	String trimmer
Cordless	Yes
Head type	Nylon line
Handle type	D-loop handle
Engine power	1.9 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Rotational speed	8500 RPM
Number of strokes	4
Sound power level	109 dB
Fuel tank capacity	0.71 L
Vibration emission	4.1 m/s²
Engine displacement	36.3 cm³
Sound pressure level	98 dB
Cutting diameter (max)	- mm

Weight and Dimensions

Length	1800 mm
Weight	5500 g
