Stihl FS 38 User Manual

FS 38
English
12
Using the Mowing Heads
Do not use with mowing line longer than
the intended length. With a properly
mounted deflector, the built-in line-
limiting blade will automatically adjust
the line to its proper length.
Using the unit with an overly long nylon
cutting line increases the load on the
engine and reduces its operating speed.
This causes the clutch to slip
continuously and results in overheating
and damage to important components
(e.g. clutch, polymer housing
components.) Such damage could,
among other things, cause the cutting
attachment to rotate at idle.
Mowing heads are to be used only on
trimmers equipped with a line-limiting
blade in the deflector in order to keep the
line at the proper length (see "Main
Parts" chapter in your instruction
manual.)
If the lawn edges are planted with trees
or bordered by a fence etc., it is best to
use a nylon line head. It achieves a
"softer" cut with less risk of damaging
tree bark etc. than polymer blades.
However, the polymer-bladed STIHL
PolyCut produces a better cut if there
are no plants along the edge of the lawn.
Sharpening is not necessary, and worn
polymer blades are easily replaced.
WARNING
To reduce the risk of serious injury,
never use wire or metal-reinforced line
or other material in place of the nylon
cutting lines. Pieces of wire could break
off and be thrown at high speed toward
the operator or bystanders.
STIHL AutoCut mowing head
Nylon cutting cord advances
automatically when tapped against the
ground (TapAction)
STIHL PolyCut mowing head 6-3
Uses nonrigid, pivoting polymer blades.
Do not continue using the PolyCut if one
of the circular holes (1; arrow) becomes
visible or if the projecting rim (2; arrow)
has worn away. Install a new mowing
head.
WARNING
If the wear limit marks are ignored, there
is a risk of the cutting attachment
shattering and flying parts injuring the
operator or bystanders. To reduce the
risk of accidents from shattered blades,
avoid contact with stones, metal and
similar solid objects. Check PolyCut
blades for cracks at regular intervals. If a
crack is found on one blade, always
replace all blades.
STIHL FixCut mowing head
Uses pre-cut lengths of nylon line.
Observe wear indicators.
000BA019 KN
1
002BA073 KN
2
002BA074 KN

Stihl FS 38 Specifications

General

Type	String trimmer
Cordless	Yes
Head type	Nylon line
Handle type	D-loop handle
Engine power	0.9 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Rotational speed	8700 RPM
Number of strokes	2
Sound power level	109 dB
Fuel tank capacity	0.33 L
Vibration emission	5.7 m/s²
Engine displacement	27.2 cm³
Sound pressure level	94 dB
Cutting diameter (max)	- mm
Power source	Gasoline

Weight and Dimensions

Length	1470 mm
Weight	4200 g
