HT 102, HT 103, HT 132, HT 133
English
23
Opening
N Raise grip to vertical position.
N Turn the cap counterclockwise
(about a quarter turn).
Marks on tank cap and oil tank must line
up.
N Remove the tank cap.
Filling the Chain Oil Tank
N Fill up with chain oil.
Take care not to spill chain oil while
refilling and do not overfill the tank.
Closing
Grip must be vertical:
N Fit the cap – marks on tank cap and
oil tank must line up.
N Press the cap down as far as stop.
N While holding the cap depressed,
turn it clockwise until it engages in
position.
The marks on the cap and oil tank are
then in alignment.
N Fold the grip down.
