Stihl HT 56 C User Manual

HT 56 C
English
23
Opening
N Raise the grip until it is upright.
N Turn the cap counterclockwise
(about a quarter turn).
Marks on filler cap and oil tank must line
up.
N Remove the cap.
Filling up with chain oil
N Filling up with chain oil
Take care not to spill chain oil while
refilling and do not overfill the tank.
Closing
Grip must be vertical:
N Fit the cap – marks on filler cap and
oil tank must line up.
N Press the cap down as far as stop.
N While holding the cap depressed,
turn it clockwise until it engages in
position.
The marks on the filler cap and oil tank
are then in alignment.
N Fold the grip down.
002BA575 KN
002BA576 KN
002BA577 KN
002BA578 KN
002BA577 KN
002BA579 KN
002BA580 KN
002BA581 KN

Stihl HT 56 C Specifications

General

Engine Power	0.8 kW (1.1 hp)
Displacement	27.2 cm³
Overall Length	280 cm
Chain Type	Picco Micro 3 (PM3)
Guide Bar Length	25 cm
Power Source	Gas
Fuel Capacity	340 cc (11.5 oz.)
