Stihl HT 56 C User Manual

HT 56 C
English
30
If there is a noticeable loss of engine
power
N Move the choke lever (1) to <.
N Turn the screw (2) in the filter
cover (3) counterclockwise until the
cover is loose.
N Ease the filter cover (3) over the
choke lever and lift it away.
N Clean away loose dirt from around
the filter.
N Reach into the recess (4) in the filter
housing and take out the felt
filter (5).
N Fit a new felt filter element (5). As a
temporary measure you can knock it
out on the palm of your hand or blow
it out with compressed air. Do not
wash.
NOTICE
Replace damaged parts.
N Fit the felt filter (5) in the filter
housing, make sure it is properly
seated – the arrow points to the
recess.
N Move the choke lever (1) to <.
N Fit the filter cover in position,
making sure the screw is square.
Tighten down the screw.
Exhaust emissions are controlled by the
design of the fundamental engine
parameters and components (e.g.
carburation, ignition, timing and valve or
port timing) without the addition of any
major hardware.
Cleaning the Air Filter
1
547BA022 KN
2
3
547BA023 KN
4
Engine Management

Stihl HT 56 C Specifications

General

Engine Power	0.8 kW (1.1 hp)
Displacement	27.2 cm³
Overall Length	280 cm
Chain Type	Picco Micro 3 (PM3)
Guide Bar Length	25 cm
Power Source	Gas
Fuel Capacity	340 cc (11.5 oz.)
