KM 55 R, KM 55 RC
English
22
1 Fuel Pump
2 Carburetor Adjusting Screws
3 Spark Plug Boot
4 Starter Grip
5 Muffler
6 Stop Switch
7 Throttle Trigger
8 Throttle Trigger Lockout
9 Choke Lever
10 Air Filter Cover
11 Fuel Tank
12 Fuel Filler Cap
13 Machine Support
14 Loop Handle
15 Barrier Bar
16 Drive Tube
17 Coupling Sleeve
18 Wing Screw
# Serial Number
Main Parts
12
9
8
7
461BA002 KN
14
6
1
5
4
2
3
15
17
18
16
8
10
11
13
#
