17KM 90, KM 90 R
English / USA
Before fueling, clean the filler cap and
the area around it to ensure that no dirt
falls into the tank.
Always thoroughly shake the mixture in
the canister before fueling your
machine.
In order to reduce the risk of burns
or other personal injury from
escaping gas vapor and fumes,
remove the fuel filler cap carefully
so as to allow any pressure build-up
in the tank to release slowly.
Opening the cap
: Raise the grip until it is upright.
: Turn the cap counterclockwise
(approx. a quarter turn).
: Remove the filler cap.
Closing the cap
: Fit the cap – grip upright –marks
must line up.
: Turn the cap clockwise as far as
stop (approx. a quarter turn).
: Fold the grip flush with the top of the
cap.
: If the grip does not lie completely
flush with the cap and the detent on
the grip does not engage the recess
in the filler neck, the cap is not
properly seated and tightened and
you must repeat the above steps.
Fueling
