25KM 90, KM 90 R
English / USA
To reduce the risk of fire and burn
injury, use only spark plugs
authorized by STIHL. Always press
spark plug boot (2) snugly onto
terminal (1) of the proper size.
(Note: If terminal has detachable
SAE adapter nut, it must be
attached.) A loose connection
between spark plug boot and
ignition wire connector in the boot
may create arcing that could ignite
combustible fumes and cause a fire.
Replacing the starter rope
: Move slide control in direction of
c – arrow to STOP-O.
: Take out the screws (1).
: Lift the starter cover (2) off the
housing.
: Remove the spring clip (3).
: Remove the rope rotor with
washer (4) and pawl (5).
1
2
002BA071 KN
Replacing Starter Rope
and Rewind Spring
1
1
249BA012 KN
2
1
4
3
5
249BA013 KN
