Stihl KM 94 R User Manual

KM 94 R
English
14
is released: The ignition is switched on
again after the engine stops – the engine
is then ready to start.
Function of throttle set wheel
The throttle set wheel (4) enables the
travel of the throttle trigger to be preset
anywhere between idle and full throttle.
– Turn throttle set wheel (4) in
direction of – to reduce throttle
trigger travel and maximum engine
speed.
– Turn throttle set wheel (4) in
direction of + to increase throttle
trigger travel and maximum engine
speed.
– It is possible to override the preset
stop and open the throttle wide by
pulling the throttle trigger firmly – the
preset stop remains unaffected. The
original setting is restored when the
throttle trigger is released.
Starting the Engine
N Press the manual fuel pump
bulb (5) at least five times – even if
the bulb is filled with fuel.
N Turn throttle set wheel in direction of
+ as far as stop.
Cold engine (cold start)
N Turn choke knob (6) and then push
it in at g
Also use this setting if the engine has
been running but is still cold.
Hot engine (hot start)
N Choke knob (6) remains in F
position.
Cranking
N Place the power tool on the ground
so that it rests on the machine
support:
N If fitted: Remove the transport guard
from the cutting attachment.
To reduce the risk of accidents, check
that the working tool is not touching the
ground or any other obstacles – see also
"Starting / Stopping the Engine" in the
KombiTool instruction manual.
N Make sure you have a firm footing,
either standing, stooping or
kneeling.
N Hold the unit firmly on the ground
with your left hand and press down
– do not touch the throttle trigger,
lockout lever or stop switch.
NOTICE
Do not stand or kneel on the drive tube.
0208BA067 KN
4
5
0208BA029 KN
2.
1.
0208BA030 KN
6
192BA002 KN

Stihl KM 94 R Specifications

General

Displacement	27.2 cm³
Power Output	0.9 kW
Weight	4.0 kg
Engine Type	2-stroke
Fuel Tank Capacity	0.35 l
Engine Power	0.9 kW
Powerhead Weight	4.0 kg
Fuel Capacity	0.54 l
