Stihl Laser 2-in-1 User Manual

14
G
Main Parts
Installing the Batteries
Batteries are supplied with the unit and packed in the pouch (1).
: Unscrew the screws (10) until they are flush with the top of the
housing and then lift off the housing (11).
: Insert batteries with polarity (+ and -) as shown.
: Refit the housing and tighten down the screws.
1 Pouch 4 Indicator lamp (on/off)
2 Laser 2-in-1 5 Rotary knob
3 On/Off switch 6 Laser diode and lens
684BA040 KN
1
2
3
4
5
6
10
11
684BA037 KN
FT_711_0000_0_06_200206_99.book Seite 14 Donnerstag, 27. Februar 2020 7:19 07

Stihl Laser 2-in-1 Specifications

General

Brand	Stihl
Model	Laser 2-in-1
Category	Measuring Instruments
Language	English
