Pomembni sestavni deli
Vstavljanje baterij
Baterije so priložene ob dobavi naprave in shranjene v torbici 1.
: odvijte vijaka (10) poravnana z zgornjim robom polovice ohišja in
snemite polovico ohišja (11)
: vstavite baterije v skladu s prikazano polariteto (+ in -)
: namestite polovico ohišja nazaj in pritegnite vijaka
1 Torbica 4 kontrolna luč (vklop/izklop)
2 laserski merilnik 2 v 1 5 Vrtljiv ročaj
3 tipka (vklop/izklop) 6 laserska dioda in optika
684BA040 KN
1
2
3
4
5
6
10
11
684BA037 KN
