Stihl MS 192 T User Manual

53MS 192 T, MS 192 TC
English / USA
EPA / CEPA:
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category:
A = 300 hours,
B = 125 hours,
C = 50 hours
CARB:
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Extended = 300 hours,
Intermediate = 125 hours,
Moderate = 50 hours
Engine
STIHL single cylinder two-stroke engine
Magneto ignition system
Electronic
Spark plug (suppressed)
NGK BPMR 7 A
Electrode gap
0.02 in (0.5 mm)
Carburetor
All position diaphragm carburetor with
integral fuel pump
Fuel tank capacity
0.57 US pt (0.27 l)
Fuel mix
see chapter on “Fuel“
Chain lubrication
Fully automatic, speed-controlled oil
pump with rotary piston
Oil tank capacity
0.46 US pt (0.22 l)
Dry weight MS 192 T
without cutting attachment:
6.6 lbs (3.0 kg)
Dry weight MS 192 TC
without cutting attachment:
7.10 lbs (3.2 kg)
Cutting Attachment
Recommended cutting attachments for
compliance with §5.11 of ANSI Standard
B 175.1-2000
(see page 14 of this Manual)
STIHL reduced kickback bar
(with green label) for 3/8" P pitch:
- Picco Micro Mini,
groove width 0.043 in (1.1 mm)
- Picco Micro,
groove width 0.050 in (1.3 mm)
Rollomatic with sprocket nose
12, 14 or 16 in (30, 35 or 40 cm)
Rollomatic E Light with sprocket nose
14 in (35 cm)
STIHL low kickback chain
1)
(with green label) for 3/8" P pitch:
3/8" P (9.32 mm) Picco Micro Mini
(61 PMMC3, 61 PMN)
3/8" P (9.32 mm) Picco Micro Comfort 3
(63 PMC3)
Chain sprocket:
6-tooth for 3/8" Picco pitch
In order to comply with the kickback
performance requirements of § 5.11 of
ANSI Standard B 175.1-2000, do not
use replacement saw chain unless it has
been designated as meeting the ANSI
§ 5.11 requirements on this specific
powerhead, or has been designated as
"low kickback" saw chain
1)
in
accordance with the ANSI B 175.1-2000
standard.
Since new bar/chain combinations may
be developed after publication of this
manual, ask your STIHL dealer for the
latest recommendations.
1)
See definition of "low kickback
chain" on page 14 of this manual.
Displacement 1.84 cu.in
(30.1 cm
3
)
Bore 1.46 in
(37 mm)
Stroke 1.10 in
(28 mm)
Idle speed 3,000 rpm
Max. chain speed 18.6 m/s
Specifications

Stihl MS 192 T Specifications

General

Engine Displacement	30.1 cc
Recommended bar length	30 cm
Engine Power	1.3 kW
Guide Bar Length	30-35 cm
Fuel Capacity	0.27 liters
Chain Oil Capacity	0.22 liters
Chain pitch	3/8"
