MS 192 T, MS 192 TC
English
46
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
CARB
The Emission Compliance Period used
on the CARB-Air Index Label indicates
the terms:
Engine
STIHL single cylinder two-stroke engine
MS 192 T, MS 192 TC
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Chain lubrication
Fully automatic, speed-controlled oil
pump with rotary piston
Weight
Cutting Attachment
Recommended cutting attachments
complying with Section 5.11 of ANSI B
175.1-2000.
Observe notes on ANSI B 175.1-2000
and definition of "low kickback chain" in
chapter on "Safety Precautions and
Working Techniques".
Rollomatic E guide bars
3/8" P chain
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Displacement: 1.84 cu. in
(30.1 cm
3
)
Bore: 1.46in. (37mm)
Stroke: 1.10in. (28mm)
Engine power to
ISO 7293: 1.7 hp (1.3 kW)
Idle speed: 3,000 rpm
High speed setting
when performing
repairs (with bar
and chain): 13,500 rpm
Spark plug (resistor
type): NGK BPMR 7 A
Electrode gap: 0.020 in.
(0.5 mm)
Fuel tank capacity: 9.1 fl.oz (0.27 L)
Oil tank capacity: 7.4 fl.oz (0.22 L)
dry, without bar and chain
MS 192 T: 6.8 lbs. (3.1 kg)
MS 192 TC: 7.10 lbs. (3.2 kg)
Reduced kickback STIHL guide bar
(with green label)
Cutting lengths: 12, 14, 16 in. (30,
35, 40 cm)
Pitch: 3/8" P (9.32 mm)
Groove width: 0.043 in. (1.1 mm)
Nose sprocket: 7-teeth
Cutting lengths: 12, 14, 16 in. (30,
35, 40 cm)
Pitch: 3/8" P (9.32 mm)
Groove width: 0.050 in. (1.3 mm)
Nose sprocket: 9-teeth
Low kickback STIHL saw chain (with
green label)
Picco Micro Mini Comfort 3
(61 PMMC3)
Pitch: 3/8" P (9.32 mm)
Drive link gauge: 0.043 in. (1.1 mm)
