43MS 210, MS 230, MS 250
: Remove the washer (arrow).
VA
208RA035
: Carefully pull the rope rotor off
the starter post.
– To replace the rope rotor, first
remove the starter rope –
b 8.5.
The rewind spring may pop out and
VA
208RA037
unwind if rope rotor is not removed
very carefully.
Installing the rope rotor:
Coat bore in rope rotor with STIHL
special lubricant – b 13.
: Fit the rotor on the starter post
so that the lug (1) on the rope
rotor slips behind the inner spring
VA
249RA141
1
2
loop (2).
Check that spring loop has engaged
by turning rope rotor slightly and
letting it go – it must spin back.
– Fit washer and push the spring
clip into the groove in the starter
post.
Make sure the spring clip (1)
engages the pawl guide peg (2) and
points in the clockwise direction.
208RA036
2
1
VA
The spring clip must be handled
very carefully. If it is bent during
disassembly or assembly, the
rewind starter may not function
properly.
– Install the starter rope – b 8.5.
– Tension the rewind spring –
b 8.5.2.

Stihl MS 250 Specifications

General

Engine Power	2.3 kW
Power output	2.3 kW
Displacement	45.4 cc
Weight	4.6 kg
Weight (without cutting equipment)	4.6 kg
Fuel Capacity	0.47 l
Fuel tank volume	0.47 l
Bar Length	40 cm
Chain Oil Capacity	0.20 l
Oil Capacity	0.20 l
Chain pitch	3/8"
