58 MS 210, MS 230, MS 250
Dirty air filters reduce engine power,
increase fuel consumption and
make starting more difficult.
The air filter should always be
cleaned when there is a
noticeable loss of engine power.
– Close the choke shutter.
: Turn twist lock (1) 90 degrees
counterclockwise.
: Lift off the carburetor box cover
(2) vertically.
– Remove all loose dirt from
around the filter.
VA
208RA019
2
Fabric/fleece filter
: Place fingers behind the filter,
press thumbs against housing,
and swing filter toward rear
handle.
– Remove the filter.
VA
135RA199
– Use compressed to blow out filter
from the clean air side.
– If the filter is caked with dirt or no
compressed air is available,
wash the filter in a fresh, non-
flammable cleaning solution (e.g.
warm soapy water) and then dry.
Replace a damaged air filter.
: To remove the filter housing,
unscrew the nuts (1 and 2) and
lift the filter housing away.
Reassemble in the reverse
sequence.
VA
208RA023
1
2
– Tighten down nuts to 2.7 Nm
(2.0 lbf.ft).
– Push air filter onto filter housing
until it snaps into position.
11. Fuel System
11.1 Air Filter
