Stihl MS 250 Spare Parts

Illustration A
MS 210, MS 230, MS 250 3
Triebwerk MS210 Shortblock MS210 Bloc moteur MS210
Bild-
Nr.
Teile-Nr. St.-
Zahl
Benennung Part Name Désignation
1 1123 020 1221 1 Zylinder mit Kolben Ø40mm
(1)
)
3-7, 13
Cylinder with piston Ø40mm
(1)
)
3-7, 13
Cylindre avec piston Ø40mm
(1)
)
3-7, 13
2 1123 020 1222 1 Zylinder mit Kolben Ø40mm
(1)
)
3-7, 13, 15
Cylinder with piston Ø40mm
(1)
)
3-7, 13, 15
Cylindre avec piston Ø40mm
(1)
)
3-7, 13, 15
3 1123 030 2003 1 Kolben Ø40mm (1)
)
4-6
Piston Ø40mm (1)
)
4-6
Piston Ø40mm (1)
)
4-6
4 1123 034 3005 2 Verdichtungsring
Ø40x1,2mm (1)
Piston ring Ø40x1.2mm (1) Segment de piston
Ø40x1,2mm (1)
5 4119 034 1500 1 Kolbenbolzen (1) Piston pin (1) Axe de piston (1)
6 9463 650 1000 2 Sprengring DIN73130-C10 (1) Snap ring10 (1) Jonc d'arrêt10 (1)
7 0000 988 5211 1 Stutzen (1) Connector (1) Manchon (1)
8 1123 030 0411 1 Kurbelwelle (1) Crankshaft (1) Vilebrequin (1)
9 9503 003 0340 2 Kugellager DIN625-6202 (1) Grooved ball bearing6202 (1) Roulementrainuréàbilles
6202 (1)
(24.96) (24.96) (24.96)
10 9638 003 1581 2 WDR BS15x25x5 (1) Oil seal15x25x5 (1) Bague d'étanchéité15x25x5
(1)
10 9639 003 1585 2 WDR DIN3760-AS15x25x5 (1) Oil seal15x25x5 (1) Bague d'étanchéité15x25x5
(1)
11 9468 621 1520 1 Sicherungsring15x1 (1) Circlip15x1 (1) Circlips15x1 (1)
12 1123 021 2500 1 Kurbelwanne (1) Engine pan (1) Carter inférieur (1)
13 9075 478 4195 4 Schraube IS-D5,3x41 (1) Pan head self-tapping screw
IS-D5.3x41 (1)
Vis cylindrique IS-D5,3x41 (1)
14 1123 020 9400 1 Dekompressionsventil
Leichtstartausführung (1)
Decompression valve Easy
start version (1)
Soupape de décompression
Version á démarrage vacil (1)
15 1122 025 2200 1 Stopfen (1) Plug (1) Bouchon (1)
16 1110 400 7005 1 Zündkerze Bosch WSR6F
(1)
Spark plug Bosch WSR6F
(1)
Bougie Bosch WSR6F (1)
16 0000 400 7000 1 Zündkerze NGK BPMR7A (1) Spark plug NGK BPMR7A (1) Bougie NGK BPMR7A (1)
0783 830 2000 1 Dichtungsmasse Dirko HT rot
(A) (1)
Tube of sealant Dirko HT red
(A) (1)
Tube de pâte d'étanchéité
Dirko HT rouge (A) (1)
(1)MS210, (2)MS230, (3)MS250

Stihl MS 250 Specifications

General

Engine Power	2.3 kW
Power output	2.3 kW
Displacement	45.4 cc
Weight	4.6 kg
Weight (without cutting equipment)	4.6 kg
Fuel Capacity	0.47 l
Fuel tank volume	0.47 l
Bar Length	40 cm
Chain Oil Capacity	0.20 l
Oil Capacity	0.20 l
Chain pitch	3/8"
