Stihl MS441 C-M User Manual

MS 441 C-M
English
25
Removing the chain sprocket cover
N Unscrew the nuts and take off the
chain sprocket cover.
N Turn the screw (1)
counterclockwise until the tensioner
slide (2) butts against the left end of
the housing slot.
Disengaging the chain brake.
N Pull the hand guarad towards the
front handle until there is an audible
click – the chain brake is
disengaged.
Fitting the chain
WARNING
Wear work gloves to protect your hands
from the sharp cutters.
N Fit the chain – start at the bar nose.
N Fit the guide bar over the studs (1) –
the cutting edges on the top of the
bar must point to the right.
N Engage the peg of the tensioner
slide in the locating hole (2) –- place
the chain over sprocket (3) at the
same time.
N Turn the tensioning
screw (4)clockwise until there is
very little chain sag on the
underside of the bar – and the drive
link tangs are engaged in the bar
groove.
N Refit the sprocket cover and screw
on the nuts only fingertight.
N Go to chapter on "Tensioning the
Saw Chain"
Mounting the Bar and Chain
143BA034 KN
1
2
001BA185 KN
001BA186 KN
143BA003 KN
3
1
1
2
4
001BA187 KN

Stihl MS441 C-M Specifications

General

Displacement	70.7 cc
Chain oil automatic adjustment	Yes
Vibration damping	Yes
Starter	STIHL ElastoStart
Engine Power	5.6 bhp
Guide Bar Lengths	40 to 71 cm (16 to 28 in.)
STIHL Oilomatic chain pitch	3/8"
Ignition system	Electronic
Fuel Capacity	24.5 oz
Chain Oil Capacity	12.2 oz
