Page #23 background imageLoading...
Page #23 background image
ENES
21
PTNOSVFIDAELBGUK
0478 121 9804 A - EN
TÜV Rheinland LGA Products GmbH
Tillystraße 2
D-90431 Nürnberg
Compilation and storage of technical
documentation:
Sven Zimmermann
STIHL Tirol GmbH
The year of manufacture and machine
number appear on the rating plate of the
machine.
Measured sound power level:
92,1 dB(A)
Guaranteed sound power level:
93 dB(A)
Langkampfen,
2019-01-02 (YYYY-MM-DD)
STIHL Tirol GmbH
Head of Design
Fault:
Motor does not start
Possible cause:
–No mains voltage
Connection cable, plug, plug connector
or switch defective
Start button not pressed
Motor is overloaded because the grass
is too tall or too wet
Motor overload protection activated
Mower housing is blocked
Fuse in plug faulty (GB version)
Remedy:
Check fuse (Ö 10.1)
Check cable/plug/switch and replace if
necessary (Ö 10.1)
Press start button (Ö 10.3)
Do not switch on motor in high grass,
adapt cutting height (Ö 7.4)
Allow machine to cool down (Ö 8.4)
Clean mower housing (Ö 11.2)
Replace fuse in plug (#)
Fault:
Frequently tripped mains fuse
Possible cause:
Unsuitable electric cable
Power overload
17. Technical specifications
Type RME 235.0
Serial number 6311
Motor, design Electric motor
Motor type Universal AC
motor
Voltage 230 V~
Power input 1200 W
Frequency 50 Hz
Fuse 5 A
Protection class II
Type of protection IPX 4
Cutting device Cutter bars
Cutting width 33 cm
Speed of cutting
device 3200 rpm
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
93 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
80 dB(A)
Uncertainty K
pA
2dB(A)
Cutter bar drive Permanent
Blade fastening
screw tightening
torque 15 - 20 Nm
Wheel diameter
(front) 140 mm
Wheel diameter
(rear) 170 mm
Grass catcher box
capacity 30 l
Cutting height 25 - 65 mm
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
1,40 m/sec
2
Uncertainty K
hw
0,70 m/sec
2
Measurement in accordance with
EN 20643
Length 127 cm
Width 37 cm
Height 108 cm
Type RME 235.0
Weight 13 kg
14 kg (GB)
18. Troubleshooting
# If necessary, contact a specialist
dealer; STIHL recommends STIHL
specialist dealers.
Type RME 235.0
