6. Spray Wand.
Feeds spray solution to the nozzle.
7. Nozzle Holder.
Accommodates the nozzle.
Nozzle.
Atomizes the spray solution.
8. Cap.
Closes the spray solution container.
9. Vent.
Allows air into container to avoid
vacuum.
10. Gasket.
Seals the container.
11. Strainer.
Helps prevent impurities entering
the container.
12. Container.
Contains the spray solution.
13. Pump.
Produces the spray pressure.
14. Retainer.
Holds spray gun when it is not in
use.
15. Hand Lever.
Pump lever for producing spray
pressure.
Contact your STIHL dealer for
information regarding special
accessories that may be available for
your product.
Specifications
Spray rate: 61 cu.in/min
(1000 cm
3
/min)
a = 31 in (80 cm)
b = 39 in (1 m)
Tank capacity: 4.75 gal (18 l)
Weight: 11.5 lbs (5.2 kg)
