Still ECU-20 - Page 93

Technical data 6
Technical data
Forks
Battery with DIN elements
DIN battery 43535 B
(standard)
l
cx
y
l
1
Wa
y
l
1
Wa
980 500 744 1105 1490 1441 1172 1557 1508
1150 600 914 1275 1660 1611 1342 1727 1678
1200 600 964 1325 1710 1535 1392 1777 1602
1450 750 1214 1575 1960 1911 1642 2027 1978
1600 800 1364 1725 2110 2061 1792 2177 2128
dimensions expressed i
n millimetres
(d008)
