Accessing the reducer and
the brake
To access the reducer and the brake:
– Turn the tiller to the right or left-hand stop.
– Unscrew the 2 screws (3)
– Unscrew the 2 screws (2) located either
side of the two 1/2 covers.
– Remove the two 1/2 covers.
Maintenance
5
Accessing the reducer and the brake
891152 807 80 01 EN - 02/2021 - 17
