DANGER
Risk of crushing feet.
Check that no one is next to the trailers before dis-
mounting the tow tractor.
The trailer lowers automatically as soon as the
operator gets up from the seat. The lowering
time is adjustable. The After-Sales Service
can set this time.
When the trailer is in the low position, the
message
Low trailers
is shown on the display.
– Disconnect the hydraulic pipe after the task
is complete.
DANGER
Risk of spraying oil and risk of injury.
Do not disconnect the pipe if the trailer is not in the
low position. Wait until the message
Low trailers
is
shown on the display.
DANGER
Risk of injury.
Do not handle the pipe union when the tractor is
switched on.
Do not mount the tractor when someone is handling
the pipe union.
Do not disconnect the pipe if someone is sitting on
the seat of the machine.
– Uncouple the trailer.
Lifting the trailer permanently
With the function to lift the trailer permanently,
you can lock the trailer in the raised position.
The operator can then mount and dismount
the tow tractor without the trailer lowering.
To activate the permanent lift function, pro-
ceed as follows:
– Park the tow tractor safely.
– Switch the tow tractor off and dismount.
– Hitch the trailer.
– Connect the hydraulic pipe union of the
trailer to the (1) nipple that is provided at
the rear of the tow tractor.
Use
4
Towing
831191 801 15 51 EN - 02/2021 - 10
