Liftrunner system equipment option
With the Liftrunner system equipment option,
the operator can lift and lower the trailer. The
function is automatically available when a hy-
draulic pipe is connected.
Lifting the trailer
– Safely park the tow tractor on level ground
– Switch the tow tractor off and dismount.
– Hitch the trailer The inching mode option is
compatible
– Connect the hydraulic pipe union of the
trailer to the (1) nipple that is provided at
the rear of the tow tractor
DANGER
Risk of injury.
Do not connect the pipe when the tow tractor is
switched on.
Do not mount the tractor when someone is handling
the pipe union.
Do not connect the pipe to the tow tractor if someone
is sitting on the seat in the tow tractor or carrier.
– Switch the tow tractor on again
– Sit on the seat.
The trailer is lifted automatically. The lifting
time is adjustable. The After-Sales Service
can set this time.
NOTE
Until the trailer reaches its maximum height,
the brake is automatically activated and the
tow tractor does not operate.
The tow tractor speed is limited to 15 km/h
when this equipment is in use.
Lowering the trailer
– Safely park the tow tractor on level ground
– Switch the tow tractor off and dismount.
Use
4
Towing
82 1191 801 15 51 EN - 02/2021 - 10
