Enabling or disabling the siren output, will only control the external siren. The internal buzzer
will always remain active.
If the control unit is connected to more than one energizer, pressing “read” repeatedly will show
the fence voltage at each energizer. (FB’s – Field Boxes)
To read the event log file
Press “read” to read the first event
Press next line to read the subsequent events (a Maximum of 100 events are stored.
Exit the user menu. New settings will only come into effect after exiting the menu.
3 Advanced Menu BS120(Press both keys simultaneouslyfor3 seconds)
Enter the advanced menu pin code. (Default pin is 1111.)
The following screen languages can be selected: English and Dutch.
Press ”select” to enter this Menu.
- - - - - - -User Menu- - - - - - - - -7
Save Settings
and exit Menu
(Exit) (Menu)
- - - - - - User Menu- - - - - - - - - 5
Read Fence Voltage
output = 6900 V
(Read) (Next Menu)
0-100 - - User Menu- - - - - - - - - 6
Read Event Log
(Read) (Next Menu)
- - - --- Advanced Menu- - - - - - 1
Enter Pin Code
0 - - -
(Increase) (Next Key)
- - - --- Advanced Menu- - - - - - 3
Read and change
calibration values
(Select) (Next Menu)
- - - --- Advanced Menu- - - - - 3.1
Select Unit to
configure: FB1
(Increase) (Enter)
1-100 - - User Menu- - - - - - - 6.1
2008-06-23 23:32
FB1 Short Circuit Zone 5
(Next line) (Next Menu)
- - - --- Advanced Menu- - - - - - 2
Select Language
English
(Change) (Next Menu)
