STINGER ELECTRONICS (PTY) LTD BS120 INSTRUCTION MANUAL REF:03/2018
Printed: 4/26/2019 Page 9 of 20
The BS120/BS102 control unit has the following features:
1 Can communicate with up to 13 BS120/BS102 units
2 Will automatically synchronize the HT pulse delivery of multiple energizer
units.
3 Can be configured for master or slave mode.
4 RS485 communication protocol.
5 Built-in time and date generator.
6 99 events memory. Data can be retrieved via LCD screen.
7 Pin protected user menu and -installer menu.
8 All energizer settings can be addressed via the keypad.
9 The BS120/BS102SMS control unit features an optional built-in modem
with full SMSout capability.
1 Fault Messages
Normal Display
Normal indication with a properly working fence.
It indicates that the unit’s address is nr. 1, it has been programmed for 20 zones, the fence
voltage is in the high (H)mode and the system is working properly.
The time and date indication is used for the event memory.
2007/01/01 0:00:17
UNIT1 H 20 ZONES
System OK
(RESET) (MENU)
